Built-in Bit Functions Provided by GCC

GCC includes built-in bit functions. These functions can perform tasks such as counting the number of 1-bits in a number, and their time complexity is O(1).

6.63 Other Built-in Functions Provided by GCC

1. Overview

In theory, counting the number of 1-bits in a number 𝑁 has a time complexity of 𝑂(log𝑁) since it involves repeatedly dividing the number by two until it becomes zero. However, using built-in functions, this task can be accomplished in 𝑂(1) time complexity.

2. Instructions

Code

For long long type literals, you need to append “ll” to the functions.

#include <iostream>

int main(){
  // 29 = 00000000 00000000 00000000 00011101 in binary
  unsigned int x = 29;

  // Count leading zeros => 27
  std::cout << "__builtin_clz(x) = " << __builtin_clz(x) << endl;

 // Count trailing zeros => 0
  std::cout << "__builtin_ctz(x) = " << __builtin_ctz(x) << endl;

 // Count number of 1 bits => 4
  std::cout << "__builtin_popcount(x) = " << __builtin_popcount(x) << endl;

 // Parity (1 if the number of 1 bits is odd, 0 if even) => 0
  std::cout << "__builtin_parity(x) = " << __builtin_parity(x) << endl;

  // 12345678987654321 = 00000000 00100011 01001011 11100010 01010001 10001010 10001110 11110101
  unsigned long long y = 12345678987654321ULL;

// Count leading zeros for long long => 10
  std::cout << "__builtin_clzll(y) = " << __builtin_clzll(y) << endl;

 // Count trailing zeros for long long => 0
  std::cout << "__builtin_ctzll(y) = " << __builtin_ctzll(y) << endl;

 // Count number of 1 bits for long long => 27
  std::cout << "__builtin_popcountll(y) = " << __builtin_popcountll(y) << endl;

 // Parity for long long => 1
  std::cout << "__builtin_parityll(y) = " << __builtin_parityll(y) << endl;

  return 0;
}

Output

__builtin_clz(x) = 27
__builtin_ctz(x) = 0
__builtin_popcount(x) = 4
__builtin_parity(x) = 0
__builtin_clzll(y) = 10
__builtin_ctzll(y) = 0
__builtin_popcountll(y) = 27
__builtin_parityll(y) = 1

3. Custom functions vs Built-in function

Comparison of execution time between the custom function and the built-in function.

Code

#include <time.h>
#include <stdio.h>

const int LIMIT = 100000000;

// Function to count the number of 1 bits using a loop
int getPopCountLoop(int num) {
    int count = 0;
    while (num) {
        if (num & 1) count++;
        num >>= 1;
    }
    return count;
}

// Function to count the number of 1 bits without using a loop
int getPopCountNotLoop(int num) {
    return (num >> 30 & 1)
         + (num >> 29 & 1)
         + (num >> 28 & 1)
         + (num >> 27 & 1)
         + (num >> 26 & 1)
         + (num >> 25 & 1)
         + (num >> 24 & 1)
         + (num >> 23 & 1)
         + (num >> 22 & 1)
         + (num >> 21 & 1)
         + (num >> 20 & 1)
         + (num >> 19 & 1)
         + (num >> 18 & 1)
         + (num >> 17 & 1)
         + (num >> 16 & 1)
         + (num >> 15 & 1)
         + (num >> 14 & 1)
         + (num >> 13 & 1)
         + (num >> 12 & 1)
         + (num >> 11 & 1)
         + (num >> 10 & 1)
         + (num >> 9 & 1)
         + (num >> 8 & 1)
         + (num >> 7 & 1)
         + (num >> 6 & 1)
         + (num >> 5 & 1)
         + (num >> 4 & 1)
         + (num >> 3 & 1)
         + (num >> 2 & 1)
         + (num >> 1 & 1)
         + (num >> 0 & 1);
}

int main() {
    int count1 = 0, count2 = 0, count3 = 0;
    clock_t start, finish;
    double duration;

    // Measure time using loop-based function
    start = clock();
    for (int i = 1; i <= LIMIT; i++) {
        count1 += getPopCountLoop(i);
    }
    finish = clock();
    duration = (double)(finish - start) / CLOCKS_PER_SEC;
    printf("%lf s <- Using Loop\n", duration);

    // Measure time using non-loop function
    start = clock();
    for (int i = 1; i <= LIMIT; i++) {
        count2 += getPopCountNotLoop(i);
    }
    finish = clock();
    duration = (double)(finish - start) / CLOCKS_PER_SEC;
    printf("%lf s <- Not Using Loop\n", duration);

    // Measure time using built-in function
    start = clock();
    for (int i = 1; i <= LIMIT; i++) {
        count3 += __builtin_popcount(i);
    }
    finish = clock();
    duration = (double)(finish - start) / CLOCKS_PER_SEC;
    printf("%lf s <- Built-in function\n", duration);

    // Print results
    printf("\n%d %d %d\n", count1, count2, count3);

    return 0;
}

Output

Time: Using Loop > Not Using Loop > Built-in function

7.639704 s <- Using Loop
0.647321 s <- Not Using Loop
0.067076 s <- Built-in function

1314447116 1314447116 1314447116

4. How these functions can perform in O(1) time complexity?

1. Hardware Support

Modern CPUs provide special instructions for bit manipulation operations, which are executed in constant time.

Examples include:

• CLZ (Count Leading Zeros): Instructions like LZCNT on x86 or CLZ on ARM.
• CTZ (Count Trailing Zeros): Instructions like TZCNT on x86 or RBIT combined with CLZ on ARM.
• POPCOUNT (Population Count): Instructions like POPCNT on x86 or VCNT on ARM.
• PARITY: Instructions like POPCNT can be used to determine parity by checking the number of 1s.

2. Compiler Optimization

The GCC and Clang compilers are optimized to translate these built-in functions directly into the corresponding hardware instructions. This means that when you use a built-in function like \(\text{__builtin_clz}\), the compiler generates code that directly utilizes the efficient hardware instructions.

3. Constant Time Execution

Since these hardware instructions are executed in a fixed number of cycles, the operations they perform (counting leading zeros, counting trailing zeros, counting the number of 1 bits, or determining parity) are completed in constant time, \(O(1)\). The complexity does not depend on the size of the input; instead, it is bounded by the nature of the instruction set of the CPU.

5. Applications

You could find the highest power of two that is smaller than or equal to 𝑛 in 𝑂(1) time complexity.

int highestPowerOf2(int n) {
    if (n <= 0) return 0; // There is an assumption that n is positive, but additional safeguards
    return 1 << (31 - __builtin_clz(n));
}

long long highestPowerOf2(long long n) {
    if (n <= 0) return 0; // There is an assumption that n is positive, but additional safeguards
    return 1LL << (63 - __builtin_clzll(n));
}
